Amplifier: Bi-Amped
Driver Configuration: 2-way
HF Driver: 1″ compression driver
LF Driver: Twin 15″ woofer
Crossover: Active crossover/voicing module
Directivity: 100 / 40 degrees
Efficiency: 101dB
Maximum SPL: 125db continuous
Frequency Response: Overall 23 Hz to 25 kHz ±1dB
Enclosure: Bass reflex
Dimensions/Weights: • Overall w/feet – 67”H x 27.75”W x 20.25”D, 516 lbs./channel
• Top cabinet – 26”H x 27.75”W x 26”D, 156 lbs.
• Horn cabinet – 6.75”H x 27.75”W x 25.75”D, 106 lbs.
• Bottom Cabinet – 26”T x 27.75”W x 26”D, 162 lbs.
• Plinth – 6.75”T x 27.75”W x 20.25”D, 87 lbs.
All specifications subject to change without notice.
