Driver 10″ front firing driver
Amplifier Class D 500 watts dynamic
250 watt RMS
Overall Frequency Response: (± 3 dB) 32 – 180 Hz
Overall Frequency Response: (± 10 dB) 25 – 250 Hz
Low Pass Crossover 50 Hz to 180 Hz (12 dB/Octave)
Phase 0 / 180 degrees
--------------------------------------------------------
Driver 12″ front firing driver
Amplifier Class D 600 watts dynamic
300 watt RMS
Overall Frequency Response: (± 3 dB) 29 – 180 Hz
Overall Frequency Response: (± 10 dB) 23 – 250 Hz
Low Pass Crossover 50 Hz to 180 Hz (12 dB/Octave)
Phase 0 / 180 degrees
----------------------------------------------------------
Driver 15″ front firing driver
Amplifier Class D 600 watts dynamic
300 watt RMS
Overall Frequency Response: (± 3 dB) 29 – 180 Hz
Overall Frequency Response: (± 10 dB) 23 – 250 Hz
Low Pass Crossover 50 Hz to 180 Hz (12 dB/Octave)
Phase 0 / 180 degrees
