Mass & Dimension
8.3g, 17.1 x 20.5 x 28.20mm (WxHxD)
Stylus
0.3 x 0.7mil Elliptical
Cantilever
⌀0.5mm Treated Aluminum Pipe
Coils
High-Purity Copper
Internal Impedance
28Ω
Load Impedance
>100Ω
Frequency Response
12Hz – 40kHz
Output
0.5mV
Channel Separation
30dB @ 1kHz
Channel Balance
<0.5dB @ 1KHz
Compliance
12×10-6cm/dyn @ 100Hz
Capacitance
100pF – 200pF
Vertical Tracking Angle
20°
Tracking Force Range
1.8g – 2.2g
Recommended Tracking Force
2.0g
