Chassis 30 kg Platter: 20 kg Motor unit: 3 kg Motor control unit: 2 kg
Dimensions
550 mm x 400 mm (W x D) Motor diameter: 119 mm Total footprint: 600 mm x 400 mm (W x D)
Chassis construction
Material: 60 mm TW ACUSTIC's proprietary Delrin-based compound, stainless disk rigidly screwed to chassis.
Feet
Three, stainless steal, height adjustable
Platter construction
Material: 40 mm copper in combination with 20 mm of our special compound let into and screwed together with the copper platter.
Bearing
Bronze bearing, 16 mm hard metal shaft with ball on top, running on a thrust washer of 'Material S ® (green)'. This is a special low-pressure PE based material with a very low coefficient of friction and very high wear resistance, giving a long maintenance free life without the need for additional lubrication. Bushing is machined exactly to fit the bearing with zero float, yet remains replaceable.
Motor
Case made from stainless steel and delrin.
Motor control unit
controlled by a microcontroller, ready for 3 motor drive
