DG X TURNTABLE
Type
Belt drive
Motor
AC Synchronous
Acetal Spindle Thrust Bearing
Motor Mount
Axially De-coupled
Pulley
Super Precision Aluminum Alloy
Drive Belt
Bespoke Silicone Rubber
Platter
Precision Machined Aluminium Alloy PETG Bonded Mat Interface
Aluminium Resonance Control Disc Protective Cork/Neoprene/Nitrile Disc
Bearing Spindle
Non Magnetic Stainless Steel
Super Precision Machined and Mirror Polished
Roundness / Concentricity
< 5 Microns
Bearing Housing
Brass Alloy
Super Precision Machined
Bore Tolerance < 5 Microns
Super Precision Tungsten Carbide Thrust Ball
Plinth Structure
3 Layer Cast Acrylic
Non-resonant Sandwiched
Clear Middle Plinth, Internally Illuminated
Isolation System
4 Position Compression
Support Structure
Black Coated Zintec Steel Chassis
+ Aluminum Resonance Control Pad
1 Rear Acetal & 2 Front Aluminium Foot Pillars Three Adjustable Feet with Resistive Felt
Motor Drive
Vertere Advanced Microprocessor Controlled Fully Programmable with Motor Noise Reduction Bridged Balanced Motor Output Amplifiers
Speeds
33.3 and 45 rpm (+/- 0.2%) Electronically Selectable
Dust Cover
Bespoke Formed Tinted Non-resonant Acrylic
Dimensions (W x D x H)
18″ x 15″ x 5″ (including dust cover)
Power Supply
VERTERE DC-2 Bespoke Desktop IEC AC Mains Input
Mains Cable – UK, EU, US, AUS
Finishes
Gloss Black, White & Red
Weights
17 lbs – Net
GROOVE RUNNER X TONEARM
Type
Tri Point Ariculated (TPA SG-1 Type)
Effective Length
240mm
Overhang
17.5mm
Offset Angle
22.9°
Tonearm Beam
Two 5-layer Flat Beams
Top & Lower Beams
Rigidly Bonded
Bearing Structure
3 Captive silicon Nitride Balls Precision Machined Non-magnetic Stainless Bearing Point
VTA Adjustable
Anti-skate System
Adjustable Stainless Weight/Thread
Progressive Across The Record
Counterweight
Stainless Steel & Special Locking Screw Fine Azimuth Adjustable Screw & End Weights
Front Beam Small Weight
Stainless Steel Block
Fine Tracking Weight and Arm/Cartridge Resonance Tuning
Internal Wiring
Vertere Pulse Wiring
& Vertere Gold Plated Cartridge Tags
Detachable from Bearing Pillar
Output
Vertere Gold Plated RCA Sockets
Multi Shield Grounding
Chassis, Signal & Floating Ground
Weight
340g
