Mass & Dimension
8.3g, 18 x 17.2 x 30.5mm (WxHxD)
Stylus
Solid Ultra Low-Mass 75µm x 2.5µm Microridge
Cantilever
⌀0.28mm Boron Shaft
Coils
High-Purity Copper
Internal Impedance
12Ω
Load Impedance
100 – 1kΩ
Frequency Response
10Hz – 50kHz
Output Voltage
0.5mV
Channel Separation
30dB @ 1kHz
Channel Balance
<0.5dB @ 1kHz
Compliance
8×10-6cm/dyn @ 100Hz
Capacitance
100pF – 200pF
Vertical Tracking Angle
20°
Tracking Force Range
1.8g – 2.2g
Recommended Tracking Force
2.0g
