Weight:
Chassis 30 kg
Platter: 10 kg
Motor unit: 3 kg
Motor control unit: 2 kg
Dimensions:
450 mm x 400 mm (W x D)
Motor diameter: 119 mm
Total footprint: 600 mm x 400 mm (W x D)
Chassis construction:
Material: 60 mm TW ACUSTIC's proprietary Delrin-based compound, stainless disk rigidly screwed to chassis.
Feet:
Three, delrin and ball, height adjustable
Platter construction:
Material: 10 mm copper in combination with 60 mm of our special compound let into and screwed together.
Bearing:
Bronze bearing, 16 mm hard metal shaft with ball on top, running on a thrust washer of 'Material S ® (green)'. This is a special low-pressure PE based material with a very low coefficient of friction and very high wear resistance, giving a long maintenance free life without the need for additional lubrication. Bushing is machined exactly to fit the bearing with zero float, yet remains replaceable.
Motor:
Case made from stainless steel and delrin.
Motor control unit:
controlled by a microcontroller, ready for 3 motor drive
Armboard:
Up to four tonearms may be fitted.
