Frequency Response
15 Hz -25 kHz
Channel Separation
Minimum 22 dB
Output Level
4.0mV (1kHz, 5cm/sec.)
Recommended Phono Input load
47 kΩ
100 pF – 220 pF
Recommended Tracking Weight
2.0 g (1.9 g – 2.1 g)
Frequency response
15 Hz -25 kHz
Channel separation
Minimum 22 dB
Cantilever
Aluminium Alloy Tube
Stylus
Elliptical Diamond
7.5 x 15.5 μm
Mounting
Special Tri-Point contact with M2.5 Threaded Fixing Holes
Generator Fixing
Special Quad-Point Contact with M2.5 Stainless ‘Spike’ Screws
Dynamic Compliance
10 x 10-⁶ cm/dyne
Coil Resistance
1 kΩ (per Channel)
Recommended Load Capacitance
100 – 200pF
Weight
10.3 g
Dimensions
17.3 (H) x 17.0 (W) x 28.2 (L) mm
