Generator Type
Moving Coil
Output
0.45mV (@ 5cm/sec.)
Recommended input load
850Ω – 1k5Ω
Recommended Tracking Weight
2.0 g (1.90g – 2.10g)
Frequency response
10 Hz -45 kHz
Channel separation
Minimum 28 dB
Coil resistance
40 kΩ
Dynamic compliance
12 x 10-⁶ cm/dyne (@100Hz)
Magnet type
Samarium Cobalt
Mounting to stylus
7.8mm
Head-shell to stylus
18.5mm
Stylus
Nude | Micro Eliptical (7.5×15.5 μm)
Cantilever
Aluminum – Telescopic
Headshell mounting
Special Vertere Tri-Point M2.5 Threaded Fixing Holes
Generator fixing
Special Quad-Point Contact Four stainless ‘spike’ screws
Net weight
11.5g
